EB150 Hydraulic Breaker For 30 Ton Excavator HB30G Side Type Rock Hammer
Product Description
Box Type
1.Reduce noise
2.Protect the environment
Side Type
1.Overall length shorter
2.Hook back things conveniently
3.Maintenance-free
Top Type
1.Easy to loCATEEEEEEEEEEEEe and control
2.More conducive to excavator
3.Weight lighter, lower risk of broken drill rod
| Model | Operating Weight(kg) | Working Flow
(L/Min) | working Pressure(Bar) | Impact Rate(bpm) | Impact Rate(bpm) | Hose Diameter(inch) | Hose Diameter(inch) |
| side | Top | box |
| HMB5G | 330 | 365 | 398 | 50-90 | 100-140 | 500-900 | 75 | 1/2 | 6-9 |
| HMB15G | 1200 | 1320 | 1310 | 90-120 | 160-180 | 350-650 | 120 | 1 | 13-18 |
| HMB20G | 1550 | 1600 | 1700 | 125-150 | 180-200 | 350-650 | 135 | 1 | 18-25 |
| HMB30G | 2380 | 2420 | 2540 | 150-190 | 180-200 | 300-550 | 150 | 1 | 25-30 |
| HMB40G | 2900 | 3020 | 3110 | 190-250 | 180-200 | 250-500 | 160 | 1 | 35-45 |
| Model | Weight (Kg) | Length (Mm) | Pressure (kg/cm2) | Flux (L/Min) | Rate (Bpm) | Hose (Inch) | Chisel (Mm) | Suit (Ton) |
| EB-45 | 130 135 120 | 1265 1280 760 | 90-120 | 15-25 | 700-1200 | 1/2 | Ø45 | 0.03-0.1
0.8-1.5 |
| EB-53 | 200 200 200 | 1342 1400 1140 | 110-140 | 25-45 | 600-1100 | 1/2 | Ø53 | 0.06-0.2
2.5-4.5 |
| EB-70 | 330 330 327 | 1590 1610 1360 | 110-160 | 30-45 | 500-900 | 1/2 | Ø70 | 0.06-0.2
2.5-4.5 |
| EB-75 | 450 450 468 | 1859 1822 1560 | 120-170 | 45-85 | 400-800 | 3/4 | Ø75 | 0.2-0.35
6-9 |
| EB-85 | 680 680 650 | 2101 2096 1774 | 150-170 | 80-120 | 400-800 | 3/4 | Ø85 | 0.25-0.5
7-14 |
| EB-100 | 1000 1000 887 | 2401 2351 1981 | 160-180 | 120-160 | 350-700 | 1 | Ø100 | 0.4-0.6
11-16 |
| EB-125 | 1300 1320 1250 | 2592 2600 2300 | 160-180 | 130-170 | 350-650 | 1 | Ø125 | 0.5-0.7
15-18 |
| EB-135 | 2000 2000 1800 | 2822 2762 2322 | 160-180 | 150-190 | 350-650 | 1 | Ø135 | 0.7-0.8
18-21 |
| EB-140 | 2050 2050 1960 | 2828 2040 2363 | 160-180 | 170-220 | 300-450 | 1 | Ø140 | 0.7-0.9
18-26 |
| EB-150 | 2800 2300 2670 | 3052 3047 2616 | 160-180 | 200-300 | 300-450 | 1 | Ø150 | 0.9-1.2
25-30 |
| EB-155 | 2800 2300 2670 | 3254 3083 2776 | 160-180 | 210-290 | 200-350 | 1-1/4 | Ø155 | 1.1-1.4
28-35 |
| EB-165 | 3400 3200 3350 | 3450 3500 3000 | 160-180 | 220-300 | 250-400 | 1-1/4 | Ø165 | 1.2-1.7
30-45 |
| EB-175 | 4200 4200 3500 | 3709 3617 3200 | 160-180 | 230-320 | 200-350 | 1-1/4 | Ø175 | 1.4-2.0
40-55 |
| EB-180 | 4500 4500 4200 | 3800 3800 3300 | 160-180 | 360-450 | 250-320 | 1-1/4 | Ø180 | 1.9-3.5
45-60 |
| EB-190 | 4650 4650 4350 | 3750 3750 3260 | 170-190 | 260-320 | 200-300 | 1-1/2 | Ø190 | 1.9-4.5
45-75 |
| EB-210 | 6350 6200 6100 | 4550 4500 4350 | 160-180 | 280-390 | 200-350 | 1-1/2 | Ø210 | 3.8-7.5
70-100 |
Factory
Payment Details
Terms & Conditions of Ordering:
1 .Payment Terms:
T/T (Telegraphic Transfer)
2. Delivery Term:
Based on order quantity, normally it takes 15 days for production.
Only 2 or 3 days if we have stock on your request size.
3. Transportation:
Sample order: we suggest Courier express or by air
Bulk order: we suggest by air or by sea.
4.Quality & Service:
A. There will be strict inspection and testing for every order before shipping out.
B Our sales team and Technical Support will response for your question within 24 hours,
WhatsApp/Wechat: + 86 18028661021
C. Free replacement will provide once the failure confirmed caused or our product quality; Not satisfied with a refund
